Ford Sierra RS Cosworth 1986
Moonstone Blue, Black or White
See specifications below illustration
Page 185B
Ford Sierra RS Cosworth Specifications
Engine (Pinto): 4 cylinder inline, aluminium cylinder head, 16 valve DOHC, Garret turbo charger and intercooler
Carburation: Weber-Marelli petrol injection
Displacement: 1,993cc
Bore & stroke: 93.82mm x 76.95mm
Compression ratio: 9.2 to 1
Power output: 204bhp at 6,000rpm
Maximum speed: 149mph
Acceleration: 0-60 6.2sec, 0-100 16.1sec
Overall fuel consumption: 21.4mpg
Drag coefficient: 0.320
Transmission: RWD, 5 speed Borg Warner T5 manual, 3.65 to 1 final drive
Construction: pressed steel monocoque
Brakes: anti-lock, hydraulic PA, vented discs 4 pot calliper F&R
Steering: rack and pinion PA
Suspension front & rear: independent coil (MacPherson strut), anti roll bars
Wheels: 13in, alloy
Wheelbase: 102.6in
Track front: 57.1in
Track rear: 57.7in
Overall length: 175.5in
Overall width: 66.0in
Overall height: 54.8in
Kerb weight: 2,656lbs
Fuel tank: 13.2gals
Numbers built: 5,542

Colours available, Black, White or Moonstone Blue, Grey upholstery
