Austin A35 Van (AV6) 1098cc 1963-68
See specifications below illustration
Page 17C
Austin A35 Van (AV6) 1098cc 1963-66 specifications
4 Cylinder inline water cooled
Displacement: 1,098 cc
Bore: 64.6mm
Stroke: 83.7mm
Valves: Pushrod/overhead
Compression ratio: 7.5:1
Carburettors: Single SU HS2
Max Power: 48bhp at 5,100 rpm

Maximum speed: 77mph
Acceleration: 0-60mph 21secs

Clutch: Borg and Beck 73/4in
single dry plate
Gearbox: 4 speed with
direct drive
in top, synchromesh on 3 upper ratios
Propellar Shaft: tubular, needle roller bearing universal joints
Rear axle ratio: 4.22/1

Construction: unitary all
steel body
Brakes: Lockheed hydraulic,
7in drums all round
Cam and peg, 2.3 turns
lock to lock

Front: Independent, coil springs with wishbones, and lever arm hydaulic shock absorbers
Rear: Live axle with semi-elliptic, leaf springs and lever arm shock absorbers

Wheels & Tyres
Pressed steel disc, 5.90 x 13in crossply

Dimensions & Weight
Wheelbase: 6ft 7in
Track - front: 3ft 9in
Track - rear: 3ft 9in
Overall length: 11ft 6in
Overall width: 4ft 6in
Overall height: 5ft 5in
Ground clearance: 61/2in
Turning circle: 32ft
Kerb weight: 15cwt
Tank capacity: 5.7 gallons
Overall fuel consumption:

A35 Commercial Production
Van: 210,576
Countryman: 5,780
Pickup: 475
