Jowett Bradford Light Van 1946-53
See larger specifications below illustration
Page 235
Jowett Bradford Light Van 1946-53 specifications

Engine: flat 2 cylinder, 4 stroke petrol, 4 side valves
Displacement: 61in3 (1,005cc)
Bore: 31/8in (72.5mm)
Stroke: 4in (90mm)
Compression ratio: 5.4 to 1
Carburettors: Zenith type 30-VM
Ignition: 12 volt battery and coil
Power output: 25hp at 3,500rpm
Clutch: 71/2in Borg & Beck
Construction: steel body on ladder-type chassis
Transmission: 3 forward speed and reverse, manual, column change, syncromesh on top only, rear wheel drive
Rear Axle: Spiral Bevel, ratio: 4.89 to 1
Brakes: mechanical, 10in drums all round
Steering: Bishop cam and lever
Wheels: 5 stud, 16in, pressed steel 5 x 16in crosply tyres
Suspension: semi eliptic leaf all round, Armstong lever arm shock absorbers

Dimensions & Weight

Wheelbase: 90in
Track 481/2in
Overall length: 144in
Width: 60in
Overall height: 69in
Track: 481/2in
Unladen kerb weight: 17cwt (1,904 lbs)
Ground clearance: 71/2in
Turning circle: 34ft

Production: 1946–1953
38,241 built
