See specifications below illustration
Page 137
Engine
6 Cylinder in line, OHV
Bore: 66.67mm
Stroke: 114mm
Displacement: 2,394cc
Carburettor: Claudel Hobson, down draught
RAC rating: 16.54hp
Performance
0-60mph: 28.5sec
Maximum speed: 72mph
Fuel consumption: 21-22mpg
Transmission
Rear wheel drive
Gearbox: 4-speed wilson self-changing preselector
Construction
Ash framed body with steel panels & aluminium bonnet. Steel ladder-type chassis
Wheels
19in bolt on wire spoke
with 5.25 x 19in crossply tyres
6 Cylinder in line, OHV
Bore: 66.67mm
Stroke: 114mm
Displacement: 2,394cc
Carburettor: Claudel Hobson, down draught
RAC rating: 16.54hp
Performance
0-60mph: 28.5sec
Maximum speed: 72mph
Fuel consumption: 21-22mpg
Transmission
Rear wheel drive
Gearbox: 4-speed wilson self-changing preselector
Construction
Ash framed body with steel panels & aluminium bonnet. Steel ladder-type chassis
Wheels
19in bolt on wire spoke
with 5.25 x 19in crossply tyres
Brakes:
Drum- Bendix semi-servo
Suspension
Front & Rear: Semi-elliptic leaf,
Dampers: Luvax hydraulic
Built in jacks
Steering
Marles worm & nut
Dimensions & Weight
Wheelbase: 9ft 3in
Track F&R: 4ft 4in
Overall length: 14ft 4in
Overall width: 5ft 4in
Turning circle: 43ft 9in
Kerb weight: 28cwt
Ground clearance: 7in
Tank capacity:12gals
Production 1934-36
482 built
Body by Burlington Coachworks, Coventry
Price new: £385,
plus £12 15s tax
