See specifications below illustration
Page 166
4 Cylinder in line
Bore: 63.5mm
Stroke: 89.0mm
Displacement: 1,125cc
Valves: 8, side
Compression ratio: 6.5 to 1
Carburation: single Zenith 26VA
Spark plugs: KLG 777
Max power: 22bhp at 4,000rpm
Performance
Maximum speed: 68mph
0-50mph: 36.5secs
Overall fuel consumption: 28mpg
Construction
Pressed steal body on crossed braced chassis
Mechanical, 7in drums
Steering
Worm and sector
Transmission
Rear wheel drive
Clutch: single, dry plate
Gearbox: 4-speed,
Synchromesh on top, 2nd & 3rd
Rear axle: threequarter floating spiral bevel
Wheels
18in wire
Tyres: 475 x 18in crossply
Suspension
Front and rear: semi-elliptic leaf
Wheelbase: 7ft 93/4in
Track - front: 3ft 101/2in
Track - rear: 3ft 101/2in
Overall length: 11ft 9in
Overall width: 4ft 7in
Overall height: 5ft 3in
Ground clearance: 71/4in
Kerb weight: 153/4cwt
Tank capacity: 6 gallons
Production
Austin 10/4 clifton 1934-36
price new in 1934: £152
Total of all Austin 10/4
(1932-48): 283,092
