Austin Seven Tourer AF 1930-32
See specifications and rally photo below illustration
Page 005 AF
Austin Seven Tourer type AF 1930-32 specifications
Engine
2 bearing, 4 in-line, side valve,
Bore: 56mm
Stroke: 76.2mm
Displacement: 747cc
Compression ratio: approx 5.5: to 1
Carburettor: single Zenith 22FZ
Power output: 10.5bhp at 2,500rpm

Performance
Maximum speed: 51mph
Acceleration: 0-50mph 24 secs
Fuel consumption: 38mpg

Transmission
Clutch: single dry plate
Gearbox: non-syncro, 3 speed manual

Construction
Steel body bolted to steel
A-form frame chassis

Steering
Worm & wheel,
1.25 turns lock to lock

Brakes
Cable operated drums all round
Suspension
Front: Beam axle with
tranverse half eliptic leaf spring
Rear: Quarter eliptic leaf springs
Austin made friction dampers

Wheels & Tyres
19” bolt-on wire, 3.50 x 19in crossply

Dimensions & Weight
Wheelbase: 6ft 3in
Track: 3ft 4in
Overall length: 9ft 2in
Overall width: 3ft 10in
Turning circle: 33ft
Kerb weight: 9cwt approx.
Tank capacity: 5 gallons

Production
1930-32 AF Tourers
(long bonnet, 75in wheelbase)
Total UK Austin 7 Saloon & Tourer
production 1922-39: 290,944
