Ford Model “Y” 8hp Tudor 1932-37 (long rad)
See specifications below illustration
Page 143
Ford Model “Y” Tudor 1932-37 specifications
4 cylinder in-line,
Valves: side, 8
Crankshaft bearings: 3
Displacement: 933cc
Bore: 56.6mm
Stroke: 92.5mm
Compression ratio: 6.2 to 1
Valves: 2 per cylinder
Carburettors: one down-draught
Power output: 23.4bhp at 4,000rpm

Maximum speed: 59mph
Acceleration 0-50: 24secs
Fuel consumption: 35mpg

4 wheel mechanical,
drums all round

Worm and nut

3 forward speed manual Synchromesh on
top 2 gears
Rear wheel drive

Steel body on separate
pressed steel channel chassis.
Front & Rear: Beam axle, transverse leaf

Wheels & Tyres
Bolt on welded 17in wire
4.50 x 17 tyres

Dimensions & Weight
Wheelbase: 7ft 6in
Track F: 3ft 9in
Track R: 3ft 9in
Overall length: 11ft 9in
Overall width: 4ft 7in
Overall height: 5ft 3in
Ground clearance: 5in
Turning circle: 33ft
Kerb weight: 15.5cwt
Fuel tank 6.5gals

'Y' Production
1932 - 1937
at Dagenham
135,238 saloons
29,606 vans
Total 164,844

Price at launch: £120
