Jaguar E Type Coupé 2+2 Series II 1969-71 specifications

Engine
6 Cylinder in line, dohc
Bore: 87 mm Stroke: 106 mm
Displacement: 3,781 cc
Compression ratio: 9:1
Valves: 2 per cylinder
Carburettors: 3 x 2in SU HD8
Power output: 265 bhp at 5,500rpm

Performance
Maximum speed: 150mph
Acceleration: 0-60 mph 7.0 secs
Overall fuel consumption: 16-20 mpg
Transmission
4-speed manual, syncromesh on top 3 ratios, Borg-Warner automatic option beginning in 1966
Ratios: Top 1:1, 3rd 1.283:1, 2nd 1.86:1, 1st 3.3771:1

Construction
Steel monocoque with square tube subframe at front, pressed steel subframe at rear

Brakes
Discs all round, inboard mounted at rear servo assisted

Steering
Rack and pinion,

Suspension
Front: Independent with torsion bars,
wishbones, anti roll bar
Rear: Independent, double spring/shock units, tranverse lower links, longitudinal radius arms

Wheels
Knock-on 15 in wire wheels with
6.40 x 15 RS5 crossply tyres

Dimensions & Weight
Wheelbase: 8ft 6.7in
Track - front: 4ft 10in
Track - rear: 4ft 2in
Overall length: 15ft 4.7in
Overall width: 5ft 5.3in
Overall height: 4ft 2in
Turning circle: 37ft
Kerb weight: 26.83 cwt

Production
E-type, All variants 1961-74
Series II 1969-71
