Page SP6

Portmierion Taxi (from the Prisoner) Lotus 7 from ThePrisoner

See specifications below illustration

PLEASE NOTE: print of Moke Taxi shown below only available from the Portmeirion souvenir shop or online...The Prisoner Merchandise

Useful Links: Portmeirion-village.com Six of One The Prisoner Appreciation SocietyPortmeiriCon

Mini Moke UK 1964-68 specifications
Engine (8MB)
4 cylinder in-line,
8 overhead valves
Displacement: 848cc
Bore: 63mm
Stroke: 68.3mm
Compression ratio: 8.3 to 1
Valves: 2 per cylinder
Carburettors: single SU HS2
Power output: 34 bhp at 5,500rpm
Torque: 44 lb/ft at 2,900rpm

Performance
Maximum speed: 65mph
0-60 mph: 21.8secs
Overall fuel consumption:
33mpg

Transmission
4-speed manual,
syncromesh on top 3 gears
Front wheel drive

Brakes
Hydraulic, Front: drum
Rear: drum

back to top

Steering
Rack & pinion

Suspension
Front & Rear: rubber cone
telescopic dampers

Wheels
Pressed steel 4 stud,
10in x 3.5J with
520 x 10in cross-ply tyres

Construction
Pressed steel monocoque

Dimensions & Weight
Wheelbase: 79.9in
Track front: 48.2in
Track front: 46.2in
Overall length: 120in
Overall width: 51.5in
Overall height: 56in
Ground clearance: 6in
Kerb weight: 10.5cwt
Fuel tank: 6.25gals

UK Moke Production
Longbridge 1964-68
Total Austin Mini Moke: 5,422
Morris Mini Moke: 9,096

Total production
(1959 - 2000) of all
Mini variants: 5,387,862
