See specifications below illustration• to Triumph Spitfire page
Page 088F
Engine
OHV 4 Cylinder in line
Bore: 73.7mm
Stroke: 76mm
Displacement: 1,296cc
Compression ratio: 9 to 1
Carburettors: single: twin SU HS2
Power output: 75bhp at 6000rpm
Performance
Maximum speed: 95 mph
Acceleration, 0-60mph: 14secs
Overall fuel consumption: 31.3mpg
Transmission
Clutch: single dry plate,
Gearbox: 4-speed, synchromesh on
2nd, 3rd and top gears
Ratios: Top 1.0, 3rd 1.39, 2nd 2.18,
1st 3.76, final drive Hypoid bevel
Final drive ratio: 4.11:1
OHV 4 Cylinder in line
Bore: 73.7mm
Stroke: 76mm
Displacement: 1,296cc
Compression ratio: 9 to 1
Carburettors: single: twin SU HS2
Power output: 75bhp at 6000rpm
Performance
Maximum speed: 95 mph
Acceleration, 0-60mph: 14secs
Overall fuel consumption: 31.3mpg
Transmission
Clutch: single dry plate,
Gearbox: 4-speed, synchromesh on
2nd, 3rd and top gears
Ratios: Top 1.0, 3rd 1.39, 2nd 2.18,
1st 3.76, final drive Hypoid bevel
Final drive ratio: 4.11:1
Construction
All metal body on backbone frame
Brakes
Hydraulic, Front: disk, Rear: drums
Steering
Rack and pinion, 3.75 turns lock to lock
Turning circle: 24ft
Suspension
Front: independent coil and wishbones
Rear: swing axle, trailing radius arms, tranverse leaf spring
Shock absorbers: telescopic front & rear
Wheels
Bolt-on disc wheels, wire wheel optional,
145 x 13” radial ply tyres
All metal body on backbone frame
Brakes
Hydraulic, Front: disk, Rear: drums
Steering
Rack and pinion, 3.75 turns lock to lock
Turning circle: 24ft
Suspension
Front: independent coil and wishbones
Rear: swing axle, trailing radius arms, tranverse leaf spring
Shock absorbers: telescopic front & rear
Wheels
Bolt-on disc wheels, wire wheel optional,
145 x 13” radial ply tyres
Dimensions & Weight
Wheelbase: 83in
Track - front: 49in
Track - rear: 48in
Overall length: 12ft 6in
Overall width: 4ft 10in
Overall height: 3ft 11in
Kerb weight: 14.5cwt
Tank capacity: 8.75 gallons
Production
Mk lll 1967-70: 65,320
Total(1962-1980 Mk1-1500): 314,332
Wheelbase: 83in
Track - front: 49in
Track - rear: 48in
Overall length: 12ft 6in
Overall width: 4ft 10in
Overall height: 3ft 11in
Kerb weight: 14.5cwt
Tank capacity: 8.75 gallons
Production
Mk lll 1967-70: 65,320
Total(1962-1980 Mk1-1500): 314,332
