See specifications below illustration
Page 138B
| BMC ADO16 drawings
Austin 1100 mk1 1963-67 Austin 1100 countryman Austin 1300GT 1969-74 MG 1100 2 door 1962-67 Vanden Plas Princess Wolseley 1100 1964-68 Morris 1100 1962-67, 1300, Morris 1100 Traveller Riley Kestral, 1100, Riley 1300 |
Engine
(tranverse mounted)
4 cylinder in-line,
8 overhead valves
Displacement: 1,275cc
Bore: 70.6mm
Stroke: 81.33mm
Compression ratio: 8.5 - 1
Valves: 2 per cylinder
Carburettors: single SU 1.25
Power output: 70bhp at 6,000rpm
Performance
Maximum speed: 91mph
Acceleration: 0-60mph 16.4secs
Overall fuel consump. : 30-35mpg
Transmission
4-speed manual,
syncromesh on top 3 gears
Front wheel drive
Construction
Pressed steel monocoque
with front & rear steel subframes
(tranverse mounted)
4 cylinder in-line,
8 overhead valves
Displacement: 1,275cc
Bore: 70.6mm
Stroke: 81.33mm
Compression ratio: 8.5 - 1
Valves: 2 per cylinder
Carburettors: single SU 1.25
Power output: 70bhp at 6,000rpm
Performance
Maximum speed: 91mph
Acceleration: 0-60mph 16.4secs
Overall fuel consump. : 30-35mpg
Transmission
4-speed manual,
syncromesh on top 3 gears
Front wheel drive
Construction
Pressed steel monocoque
with front & rear steel subframes
Brakes:
Hydraulic, Front: disc Rear: drum
Steering
Rack & pinion
Suspension
Independent/Hydolastic suspension
Wheels
4 stud, 12in, pressed steel
Dimensions & Weight
Wheelbase: 93.5in
Track front: 51.5in
Track rear: 50.9in
Length: 146.7in
Width: 60.4in
Height: 52.7in
Ground clearance: 6in
Kerb weight: 1,973 lbs
Fuel tank: 8.0gals
Vanden Plas 1300 1968 -1975
Total production:27,734
Hydraulic, Front: disc Rear: drum
Steering
Rack & pinion
Suspension
Independent/Hydolastic suspension
Wheels
4 stud, 12in, pressed steel
Dimensions & Weight
Wheelbase: 93.5in
Track front: 51.5in
Track rear: 50.9in
Length: 146.7in
Width: 60.4in
Height: 52.7in
Ground clearance: 6in
Kerb weight: 1,973 lbs
Fuel tank: 8.0gals
Vanden Plas 1300 1968 -1975
Total production:27,734
